Products Show
It is suitable for testing the winding or torsion of various wire and wire products, and is used for testing the material properties and fatigue strength of wire.
Technical Parameters
| Nubmer of winding settings | 1~9999999sec |
| Fold the starting position | 0~1000mm |
| Wrap the end position | 0~1000mm |
| Winding displacement accuracy | ±1mm |
| Around the discount rate | 10~400mm/sec |
| Wrap pause time | 0~99.9sec |
| Minimum displacement display | 0.1mm |
| Rotation angle range | -360°~360° (0~360°) |
| Minimum angle display | 0.1° |
| Rotation angle error | ±0.5° |
| Rotation speed range | 5~60rpm |
| Pause time | 0~99.9sec |
| Rotation range | 1~9999999sec |
| The machine size | W2050xD800xH1500mm |
| Weigh | 240kg |
| Power | AC220V 50HZ 5A |
